In order that employees have central access to corporate data, e.g. customer information, sales figure, e-mails, etc., it is necessary to network all parts of the company. As soon as mobile employees, home offices, subsidiaries or branches access the corporate server via WAN, data are insecure.
This opens the door for hackers. Especially for companies like this, it is essential to make data traffic secure. Because data transmitted insecurely can be read, falsified or manipulated by hackers.
Solution
A Virtual Private Network (VPN) is the most secure and economical way of transmitting corporate data. A VPN is like a shielded tunnel connecting the sender and receiver. Outsiders have no access to this tunnel. Data and e-mail can therefore be exchanged securely within the corporate network.
Even phone calls made via the Internet can be protected with VPN - this is then termed Voice over VPN (VoVPN).
Benefit / Highlights
Benefit / Highlights
- Highest security level during data transfer by means of the certificate support;
- VPN as basic technology for advanced services, such as VoIP or VoVPN;
- Secure data connection also via WLAN;
- Secure connection of mobile employees to the corporate network;
- Creation of a cross-site, transparent network infrastructure;
- ISDN backup;
- Certificate handling;
Hardware
Hardware
bintec RS353jwv
- WLAN- 802.11n, 2,4 and 5 GHz;
- VDSL2 / ADSL2+ / ISDN Modem- (Annex B/J);
- Vectoring ready;
- 5x IPSec-tunnels (optional 30 tunnels);
- HW acceleration, Integrated Power Supply;
- Flexible mounting: Desktop or 19”- Rack;
- Stateful Inspection Firewall;
bintec RXL series
The high-performance central site VPN Gateway
- 10 x Gigabit Ethernet therfrom 2 SFP;
- RXL12100: 25 IPSec tunnels (opt. up to 200);
- RXL12500: 100 IPSec tunnels (opt. up to 2500 with hardware accerleration);
- 19-inch housing;
- Integrated power supply (optional redundant);
- IPv6;
- Extended Routing and NAT (ERN);
- BRRP and Load Balancing;
bintec R1202
The flexible VPN gateway for all cases
- 5 x Gigabit Ethernet;
- 19 inch housing with integrated power supply;
- Web-based configuration / wizards;
- IPSec - 10 tunnels, opt. up to 110, HW acceleration;
- IPv6;
- Stateful Inspection Firewall;
- SIP Application Level Gateway;
- PABX for up to 40 users (SIP-Trunk ready);
- Supports analogue, ISDN and IP/IP DECT end devices;
- 4 additional analogue interfaces Opt. enhancment of user, Voicemail, VPN and WLAN Management;
- Flipable ISDN Interface by Optional Adapter;
- LANCAPI;
- supported Smooth migration - operation mode as media gateway;
